USD $199.30 USD $359.50Price range: USD $199.30 through USD $359.50
Single glass shower door handle / towel bar.
• Solid stainless steel construction.
• Connection hardware included for glass thickness ranging from 3/8″ [10mm] and 1/2″ [12mm]
• Available downloads below for CAD – 3D – PDF Specifications
FOR OPTIONAL COLOR MATCHING OR SPLIT FINISH BACKPLATES:
A single-sided straight-bar shower door handle with integrated towel bar, hand-welded in solid 304 stainless steel, thru-glass mounted with a matching back cap, 2″ (51 mm) projection, in 18″, 24″ and 30″ center-to-center lengths. Fitted to glass shower doors, swing doors and screens where one face is gripped and the other stays clean. Designed and assembled in Vancouver, BC; in-stock orders ship in 1–3 workdays to Canada and the US.
| Profile | ‘I’ – straight bar, both ends squared, with towel bar |
| Material | Solid 304 stainless steel, hand-welded |
| Bar section | 1″ x 1/2″ D-profile |
| Projection (from door face) | 2″ (51 mm) |
| Overall length | 18-1/2″, 24-1/2″, 30-1/2″ |
| Center to center | 18″, 24″, 30″ |
| Mount | Single-sided thru-glass with matching back cap; connection hardware included |
| Glass thickness | fits 3/8″ and 1/2″ (10–12 mm) tempered glass. Gaskets included. |
| Glass hole | 3/8″ (10 mm) or as per glass manufacturer spec. Do not drill tempered glass; holes must be cut before tempering. |
| Finishes | Brushed, Polished, Matte Black, Satin Brass PVD, White |
| Applications | Glass shower doors, swing doors, screens and partitions |
| Origin | Designed and assembled in Vancouver, BC |
| Shipping | In-stock orders ship in 1–3 workdays from Vancouver, BC; Canada and US; free shipping over $500 |
| Warranty | Limited lifetime residential warranty on materials and workmanship (commercial: 5 yr brushed stainless, 2 yr coated). Full terms: jwlhome.com/warranty |
| Downloads | DWG (CAD), 3D, PDF spec sheet |
‘I’ profile: a straight bar squared at both ends, on a 1″ x 1/2″ D-section, with both legs returning to the glass. Overall lengths 18-1/2″, 24-1/2″ and 30-1/2″ (center to center 18″, 24″, 30″). Five finishes: Brushed, Polished, Matte Black, Satin Brass PVD and White. The bar doubles as the towel rail.
Thru-glass mount with connection hardware included; a matching back cap closes the reverse face. Choose the length by the width of the door: a 24″ C/C bar suits most 28″–32″ shower doors. Optional color-matched or split-finish backplates are sold separately. DWG, 3D and PDF spec sheet downloads are on the page.
Rinse and dry after showering; clean with mild soap and a soft cloth. Avoid abrasive pads, bleach and chloride cleaners on stainless or coated finishes. Limited lifetime residential warranty on materials and workmanship (commercial: 5 yr brushed stainless, 2 yr coated). Full terms: jwlhome.com/warranty
The 24-1/2″ overall (24″ center to center) bar is the usual choice for a 26″–32″ door, leaving clear glass on either side and enough rail for a bath towel. Use the 18″ C/C for narrow doors under about 26″ and the 30″ C/C for doors 34″ and wider.
This handle fits 3/8″ and 1/2″ (10–12 mm) tempered glass; gaskets are included. Holes must be cut before tempering — do not drill tempered glass. Send the CAD and PDF spec sheet to your glazier before the glass is ordered.
304 stainless steel is the standard grade for bathroom hardware and is used for this handle in all five finishes. Rinse and dry the bar after use and avoid chloride-based cleaners to keep the finish in good condition. Coated finishes (Matte Black, White, Satin Brass PVD) carry a 2-year commercial warranty.
The set is single-sided: one handle-and-towel-bar on the outside of the glass and a matching back cap that closes the fixings on the inside. If you want a grip on both faces, order the back-to-back glass door handle set instead.
In-stock orders ship in 1–3 workdays from Vancouver, BC, to Canada and the US, with free shipping on orders over $500. The handle carries a limited lifetime residential warranty on materials and workmanship (commercial: 5 yr brushed stainless, 2 yr coated). Full terms: jwlhome.com/warranty.
