This page lists three JWL options for integrated dishwasher panels: the I series cabinet pull (192, 256 or 320 mm center to center, 1″ projection), the I thru-bolt handle (18 1/2″, 24 1/2″ or 30 1/2″, 2″ projection) and the 3″ U handle (2″ projection), all hand-welded solid 304 stainless steel in five finishes. They mount through the millwork panel of any panel-ready dishwasher and match JWL cabinet pulls and fridge handles. For wood-front kitchens, solid white oak or walnut thru-bolt handles (the 12 5/8″ narrow bar suits most dishwasher panels) are also available and match the wood fridge handles. Designed and assembled in Vancouver, BC.
I-shaped Dishwasher Pull Series
The I series solid stainless steel pull is commonly used on dishwasher doors with integrated millwork panels. Mounting hardware included for door thicknesses ranging from 10mm [3/8″] to 25mm [1″] thick.
To see specifications, pricing, finish options and downloads, please select one of the length buttons below:
I-shaped Dishwasher Handle Series
The I series solid stainless steel handle is commonly used on dishwasher doors with integrated millwork panels. Mounting hardware included for panel thicknesses from 3/4″ to 2 1/4″ (19–57 mm).
To see specifications, pricing, finish options and downloads, select the PULL button below:
U-shaped Dishwasher Handle Series
The U series solid stainless steel handle is commonly used on dishwasher doors with integrated millwork panels. Can be mounted vertically or horizontally. Mounting hardware included for panel thicknesses from 3/4″ to 2 1/4″ (19–57 mm).
To see specifications, pricing, finish options and downloads, select the PULL button below:
How to choose
- Match the rest of the kitchen: if drawers use I series pulls, use the 256 or 320 mm pull on the dishwasher
- For a full-width bar across the panel, choose the I thru-bolt handle, typically 24 1/2″ on a 24″ dishwasher
- For a compact grip, the 3″ U handle projects 2″ and mounts vertically or horizontally
- Confirm panel thickness before ordering: thru-bolt handles include hardware for 3/4″–2 1/4″ panels
- Pick one of five finishes to match the fridge and wine-fridge handles
What’s on this page
Length buttons for the I series pull (192/256/320 mm) and PULL buttons for the I-TB handle and U-TB handle. Each product page shows pricing by finish, projection, included hardware and DWG, 3D and PDF spec-sheet downloads.
Compare the products on this page
| Product | Mount | Projection | Sizes | Page |
|---|---|---|---|---|
| I Series Cabinet Pull (dishwasher) | Rear 8-32 screws through panel | 1″ (25 mm) | 192/256/320 mm | View |
| I Shape Door Handle – Thru-Bolt | Thru-bolt, M5 | 2″ (51 mm) | 18 1/2″, 24 1/2″, 30 1/2″ | View |
| U Shape 3″ Door Handle – Thru-Bolt | Thru-bolt, M5 | 2″ (51 mm) | 3″ | View |
Frequently asked
Will these fit a panel-ready Bosch, Miele, Thermador, Sub-Zero or Fisher & Paykel dishwasher?
Yes. The handle mounts through the custom millwork panel fitted to the dishwasher door, not the appliance, so it works with any panel-ready dishwasher including Bosch, Miele, Thermador, Sub-Zero and Fisher & Paykel. Thru-bolt hardware covers 3/4″–2 1/4″ (19–57 mm) panels and the handle projects 2″ (51 mm) from the panel face.
Which size should I choose for a 24-inch dishwasher panel?
A 24 1/2″ I handle spans most of a 24″ panel; an 18 1/2″ handle leaves wider margins. Among the pulls, 256 mm (10″) and 320 mm (12.5″) are the common choices on a dishwasher because they match the pulls on adjacent drawers. Handles can be mounted horizontally or vertically.
What is the projection and will it clear the counter overhang?
Thru-bolt I and U handles project 2″ (51 mm) from the panel face; I series pulls project 1″ (25 mm). Standard counter overhangs of 1″–1 1/2″ clear both, but check that a horizontally mounted top handle sits below the overhang line on the panel.
Which finishes are available?
All stainless handles and pulls come in five finishes: Brushed, Polished, Matte Black, Satin Brass PVD and White. The same five finishes run across cabinet pulls, appliance handles, door handles and glass door handles, so one finish can be carried through a kitchen, bathroom and closet without mixing suppliers.
How fast do orders ship, and what is the warranty?
In-stock orders ship in 1–3 workdays from Vancouver, BC to Canada and the US, with free shipping on orders over $500. Stainless handles carry a limited lifetime residential warranty on materials and workmanship (commercial: 5 yr brushed stainless, 2 yr coated). Full terms are at jwlhome.com/warranty.
