Single door handle – 3 inch centre to centre
• Solid stainless steel construction
• Connection hardware included for door thickness ranging from 3/4″[19mm] to 2 1/4″[57mm]
• See available downloads below for CAD – 3D – PDF Specifications
3-Inch ‘U’ Door Handle – Thru-Bolt Mount, Stainless Steel
CAD $72.90 CAD $114.25Price range: CAD $72.90 through CAD $114.25
- In-stock orders ship in 1–3 workdays from Vancouver, BC
- Free shipping on orders over $500 · US orders ship duties paid
- Limited lifetime residential warranty
- Trade pricing and free finish samples for design offices and showrooms
- 30-day returns and exchanges · no exchange fee in Canada
Product details
A 3″ ‘U’ door handle in hand-welded solid 304 stainless steel with a concealed thru-bolt mount and a 2″ (51 mm) projection from the door face; one size, 3″ (76 mm) center to center and 3 1/2″ overall. The short ‘U’ is for doors that need a real grip but no visual length: dishwasher and beverage-fridge panels, narrow pantry doors, and cabinet doors that sit next to a full-height handle and should not compete with it. Designed and assembled in Vancouver, BC; in-stock orders ship in 1–3 workdays.
Specifications
| Profile | ‘U’ — both ends return to the door; D-section bar |
| Material | Solid 304 stainless steel, hand-welded |
| Bar section | 1″ x 1/2″ (25 x 13 mm) D-profile |
| Projection (from door face) | 2″ (51 mm) |
| Overall length | 3 1/2″ (89 mm) |
| Overall size | 1″W x 3.5″L x 1.5″H (c/c 3″); 1.5″ leg + 1/2″ bar = 2″ projection |
| Center to center | 3″ (76 mm) |
| Mount | Thru-bolt, single-sided; concealed fasteners; connection hardware included |
| Door thickness | 3/4″–2 1/4″ (19–57 mm) |
| Finishes | Brushed, Polished, Matte Black, Satin Brass PVD, White |
| Applications | Dishwasher and beverage-fridge panels, freezer drawers, narrow pantry and cabinet doors |
| Origin | Designed and assembled in Vancouver, BC; manufactured in China |
| Shipping | In-stock orders ship in 1–3 workdays from Vancouver, BC; free shipping over $500 |
| Warranty | Limited lifetime residential warranty on materials and workmanship (commercial: 5 yr brushed stainless, 2 yr coated). Full terms: jwlhome.com/warranty |
| Downloads | DWG (CAD), 3D, PDF spec sheet |
Profile
The ‘U’ is a symmetrical return: both ends of the 1″ x 1/2″ D-section bar turn back to the door, so the handle reads as a small, closed loop rather than a bar with ends. It uses the same bar section, 2″ projection and five finishes as the 18–30″ ‘I’, ‘J’ and ‘L’ handles, so it works as the short member of a set.
Installation
Two thru-bolts from the back of the door or panel; no visible fasteners on the face. Connection hardware for doors 3/4″ to 2 1/4″ thick is included. Drill two holes at the spacing on the DWG or PDF drawing in Downloads. On panel-ready appliances the handle bolts through the custom panel, not the appliance door.
Care
Solid 304 stainless steel resists corrosion in kitchens and bathrooms. Wipe with a damp cloth and mild soap and dry. Avoid chlorine-based cleaners and abrasive pads on the coated Matte Black, Satin Brass PVD and White finishes. Check thru-fixings once a year and snug them if the door has moved.
Frequently asked
Is 3 inches the overall length or the center-to-center spacing?
3″ (76 mm) is the center-to-center hole spacing. The handle measures 1″W x 3.5″L x 1.5″H, so the bar is 3 1/2″ long end to end with the two thru-bolt holes 3″ apart. Drill to the 3″ spacing; the DWG and PDF spec sheet in Downloads show the same figure.
Which appliances is the 3-inch handle intended for?
Panel-ready dishwashers, beverage and wine fridges, freezer drawers and compact appliance panels from any brand, where a full-length bar would be out of scale. It also suits narrow pantry and cabinet doors next to a tall ‘I’, ‘J’ or ‘L’ handle. Confirm the panel thickness is 3/4″–2 1/4″.
What door thickness does the thru-bolt hardware fit?
Fixing hardware for doors and panels from 3/4″ (19 mm) to 2 1/4″ (57 mm) thick is included with every thru-bolt handle. That range covers standard interior doors, appliance panels and most millwork. For thicker doors, contact JWL for longer bolts before ordering.
How far does the 3-inch handle stand off the door?
2″ (51 mm) from the door face to the outside of the bar — the same projection as the full-length JWL door handles, so a 3-inch grip and a 30-inch bar sit at the same depth on adjacent doors. The handle measures 1″W x 3.5″L x 1.5″H; the 1.5″ leg plus the 1/2″ deep bar gives the 2″ total.
Which finish should I choose, and will it match JWL cabinet pulls?
All five finishes — Brushed, Polished, Matte Black, Satin Brass PVD and White — are shared across JWL door handles, back-to-back sets and cabinet pulls, so one finish can run through a whole kitchen. Brushed and Polished are bare 304 stainless; Matte Black, Satin Brass PVD and White are coatings over the stainless. Order a hardware sample if you need to check colour against your cabinetry.
How quickly does it ship, and what is the warranty?
In-stock orders ship in 1–3 workdays from Vancouver, BC, to Canada and the US, with free shipping on orders over $500. JWL hardware carries a limited lifetime residential warranty on materials and workmanship; commercial installations are covered for 5 years on brushed stainless and 2 years on coated finishes. Full terms are at jwlhome.com/warranty.
